Gensler Technical Resources for Building Professionals
Specification sheets, installation guides, CAD drawings, and engineering data organized for architects, specification writers, and contractors coordinating building panel packages. Every downloadable set is keyed to a board core and finish SKU so STC rating, fire resistance rating, and VOC emissions figures cannot be mixed across catalog siblings that only look similar in a render.
Resources are written for constructability reviews: clip schedules, substrate flatness tolerances, moisture vapor transmission notes, and ASTM-referenced compressive strength or flexural strength letters. If a figure depends on the full wall assembly, the sheet states that dependency instead of implying a stand-alone board rating.
Resource inventory by discipline
Use this matrix to locate the correct package before requesting downloads or sample kits. Content themes focus on constructability—not sustainability slogans.
| Resource set | Primary audience | Includes | Update cadence |
|---|---|---|---|
| Specification sheets | Specification writers | STC rating, fire resistance rating, VOC emissions, recycled content percentage | Quarterly |
| Installation guides | General contractors | Substrate prep, clip torque, moisture vapor transmission notes | Bi-annual |
| CAD / BIM details | Architects & detailers | Joint conditions, corner modules, expansion strategies | Per release |
| Engineering data packs | Structural / fire engineers | Compressive strength, flexural strength, impact resistance reports | Per test campaign |
| Finish & maintenance manuals | Facility managers | Cleaning chemistry, UV stability care, service life expectancy | Annual |
Documentation checklist before bid
Confirm these items are in your project folder to avoid AHJ delays and incomplete submittals.
- ✓ Current specification sheet matching the exact board core and finish
- ✓ Fire resistance rating letter referenced to the tested assembly
- ✓ Acoustic report with STC rating for the demising or ceiling condition
- ✓ CAD details for outside corners, reveals, and termination at dissimilar materials
- ✓ Installation guide covering substrate flatness and fastener pattern
- ✓ VOC emissions and material transparency documentation for LEED/WELL files
- ✓ Maintenance schedule aligned to the facility cleaning chemistry
Technical trade-offs documented in our packs
Specification writers routinely weigh prefabricated panel modules against traditional on-site framing, and green-credit documentation against bid-day cost. Our packs present both sides with the performance data each path still requires.
Prefabricated modules vs. field-built partitions
Factory modules improve dimensional stability and reduce on-site waste when elevations repeat; traditional stick-built framing retains flexibility at irregular cores and late design changes. Either route still needs the same fire resistance rating letter for the final assembly—prefabrication does not waive AHJ testing references.
Green documentation vs. budget pragmatism
Higher recycled content percentage and lower embodied carbon cores can support LEED strategies, yet some binders lengthen cure windows before finish coats. When budgets force substitutions, keep STC rating and fire resistance rating intact first; re-issue VOC emissions and material transparency sheets only after the alternate core is confirmed.
- ! Acoustic reports assume sealed penetrations; flanking paths invalidate published STC rating gains.
- ! Exterior UV stability claims do not apply to interior-only coatings moved outdoors without retesting.
- ! Impact resistance grades are zone-specific—lobby wainscot data should not be copied onto unprotected exterior podium walls.
Request a technical documentation package
List the elevations and performance targets—we will assemble the matching sheets, guides, and CAD set.
